TH55 - ESD Fabric

Static dissipative fabric (Carbon loaded yarns in 5 mm grid), IEC/TS 61340-4-9:2016 Electrical properties maintained after more than 50 industrial launderings

Available colours:

Royal Blue (RB), Light Blue (LB), Grey (GA), White (W)

TH55 - ESD Fabric

FEATURES
  • Static dissipative woven fabric (carbon loaded yarns in 5 mm grid)
  • Composition: 63% Polyester 33% Cotton 4% Conductive fiber
  • Fabric Weight: 155 g/m2
  • Finish: Crease resists, workwear
  • Resistance from point to point (Rp): 106 - 107 Ohm
  • Charging time: < 2 seconds
  • Electrical propoerties maintained after more then 50 industrial washings according to IEC/TS 61340-4-9:2016 and ANSI/ESD STM2.1:2018
  • Complies with IEC/TS 61340-4-9:2016 and ANSI/ESD STM2.1:2018
  • Developed for industrial washing



AVAILABLE COLOURS

Royal Blue (RB), Light Blue (LB), Grey (GA), White (W)

Szinek

WASHING INSTRUCTIONS
  • Machine washable up to 40 °C
  • Ironing at maximum 110 °C
  • Do not use acid or alkali!
  • Do not bleach!
  • Tumble dry at low temperature

ICON

WARRANTY
  • The warranty is strictly valid under controlled and documented industrial laundry conditions, concern the fabric washing cycle as specified in the technical data’s.
  • The warranty is NOT valid if the washing process is made in a home enviroment!
  • The warranty covers ESD parameters and possible sewing errors according to IEC/TS 61340-4-9:2016 and ANSI/ESD STM2.1:2018 standard issued only!
  • The warranty is not cover the size and shrinkage differences within the tolerances given on the size cart!
  • If the product shows improper tampering (e.g. tread extension or tearing), the complaint can be rejected.
