KK01 - ESD Fabric

Static dissipative fabric (Carbon loaded yarns in 5 mm grid), ANSI/ESD STM2.1:2018 Electrical properties maintained after more than 50 industrial launderings

Available colours:

Black (BK), Dark Green (DZ), Dark Gray (DG), Light Gray (LG), Grey (GA), White (W), Navy Blue (NB), Royal Blue (RB), Light Blue (LB), Mint Green (MG), Light Green (LE), Burgundy (B), Red (R), Orange (O), Yellow (Y), Light Pink (LPK)

KK01 - ESD Fabric

FEATURES
  • Static dissipative woven fabric (carbon loaded yarns in 5 mm grid)
  • Composition: 74% Polyester, 24% Cotton, 2% Conductive fiber
  • Fabric Weight: 125 g/m2
  • Finish: Crease resists, workwear
  • Resistance from point to point (Rp): 106 - 107 Ohm
  • Charging time: < 2 seconds
  • Electrical propoerties maintained after more then 50 industrial washings according to IEC/TS 61340-4-9:2016 and ANSI/ESD STM2.1:2018
  • Complies with IEC/TS 61340-4-9:2016 andANSI/ESD STM2.1:2018
  • Developed for industrial washing



AVAILABLE COLOURS

Black (BK), Dark Green (DZ), Dark Gray (DG), Grey (GA), Light Gray (LG), White (W), Navy Blue (NB), Royal Blue (RB), Light Blue (LB), Mint Green (MG), Light Green (LE), Burgundy (B), Red (R), Orange (O), Yellow (Y), Light Pink (LPK)

Szinek

WASHING INSTRUCTIONS
  • In order to preserve the long life of ESD clothings, please use industrial laundries who can provide controlled, documented washing procedures and environment
  • Wash in cold or not warmer than 40 oC (104 oF) lukewarm water with neutral liquid detergent
  • Do not use detergents and / or rinse aids that contain bleach and / or chlorine
  • Bleachers are forbidden
  • Do not use rinse aids or detergents with a high alkali or high acid content
  • Do not dry clean
  • Dry in the open air and / or at a temperature up to 50 oC (120 oF)
  • Does not require ironing, but if absolutely necessary, iron at a maximum temperature of 110 oC (230 oF) without steaming
  • Wash all items inside out
  • Using deodorant can damage the color of the product
  • When drying clothes outdoors, do not expose them to direct sunlight
  • Tighten the zippers before each wash

ICON

WARRANTY
  • The warranty is strictly valid under controlled and documented industrial laundry conditions, concern the fabric washing cycle as specified in the technical data’s.
  • The warranty is NOT valid if the washing process is made in home environment!
  • The warranty covers ESD parameters and possible sewing errors according to IEC 61340-4-9:2016 and ANSI/ESD STM2.1:2018 standard issued only!
  • The warranty does not cover the size and shrinkage differences within the tolerances given at the size charts!
  • Our clothing products are provided with the "Operating instructions with symbols” according to the MSZ EN ISO 3758:2012 standard.
  • If the product shows improper tampering (e.g. tread extension or tearing), the complaint can be rejected.
